14.Benz front axle and rear axle, for military using.
Driving type |
4x4 |
||
Dimension(Lx W x H) (unloaded) (mm) |
8826x2500x3215 |
||
Inner dimension (mm) |
6500x2300x600 |
||
Approaching angle/Departure angle(°) |
30/26 |
||
Overhang(front/rear) (mm) |
1410/2616 |
||
Wheel base (mm) |
4800 |
||
Max speed (km/h) |
90 |
||
Curb weight (kg) |
7980 |
||
Engine Styr technology, made in China |
Model (WP10.300N) |
WEICHAI Diesel engine, water-cooled, four strokes, 6 cylinders in line, turbocharged, directly injection |
|
Displacement (L) |
9.726/Diesel |
||
Bore x stroke (mm) |
126/130 |
||
Max power (kw/rpm) |
221/2200 |
||
Max torque (Nm/rpm) |
1390/1200-1500 |
||
Emission |
EURO III |
||
Clutch |
Model |
Single dry frictional disc, Hydraulic boosting |
|
Gearbox |
Model |
RT11509C, mechanism,9gears,1reverse gear, manual |
|
Brake system |
Service brake |
Double circulation air brake system |
|
Assistant brake |
Engine exhaust brake |
||
Park brake |
Potential springs pressing on middle and rear wheels |
||
Steering system (ZF company) |
Model |
TAS85,whole circulation in ball, hydraulic booster |
|
Frame |
Fish belly, shape, variable width, variable sections, side beam structure |
||
Front axle (Mercedes Benz) |
Double-shoe pneumatic brake, non-driving steering axle |
||
Middle and Rear axle (Mercedes Benz Technology) |
Double-shoe pneumatic brake, casting, double reduction driving axle |
||
Tyre |
12.00-20 |
||
Electrical system |
Battery |
2X12V/135Ah |
|
Generator |
28V-35A |
||
Starter |
5.4Kw/24V |
||
Cab |
Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly, short cabin without sleeper |
