Beiben 6x4 dump truck

Home Beiben Dump Truck Beiben 6x4 dump truck

Low price for high quality China 30 ton truck 6X4 beiben dump truck

Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks
Low price for high quality China 30 ton truck 6X4 beiben dump trucks

Low price for high quality China 30 ton truck 6X4 beiben dump truck

1. High qualtiy 380hp dump truck

2. Competitive price for sinotruk howo dump truck

3.Good service and after sales for howo dump truck

4. Front tipper system 30 ton dump truck 6x4

5. howo dump truc
  • Order(MOQ):

    1
New Products

Low price for high quality China 30 ton truck 6X4 beiben dump truck



 china beiben 2538 dump truck

POWER-TRAIN WARRANTY

We offer an industry leading power-train warranty of 18 months or 150,000km whichever comes first. It simply means that for 18months or 150,000km you have TOTAL peace of mind regarding your engine, transmission and axles. Any issues and your power-train warranty cover the cost at no expense to you.

GERMAN QUALITY DNA

Beiben trucks thanks to German and Mercedes Benz technology and heritage are manufactured to the highest international standards and the strictest military quality controls. Our prices are considerably lower than European, American and Asian competitors; including Mercedes Benz Actros sold in Nigeria.
The decision to buy a truck takes into account many factors, but most important is the confidence to deliver consistent service over many years with little down time and expense, all while delivering excellent fuel mileage. Beiben is the only Asian heavy duty truck company capable of providing the quality found among European and American manufacturers. This is because Beiben is actually a truck with German technology and heritage, but produced in Asia.. Beiben trucks are designed to support over 70% overload while traveling at 80km/h and at over 5,000 meters high. Beiben trucks and Mercedes Benz trucks share many features such as HL7, HD7 and VL4 axles used in the Actros and Atego models. They both share familiar gearboxes - ZF and Fuller Fast. Beiben trucks are offered with these engines - Mercedes Benz and Weichai WD615, WP10 and WP12. They comply with Euro 2, 3 and 4; have displacements of 10 and 12 liters and HP of 270 to 480. Bosch Common Rail injection, the Euro 2 with linear pump, motor and brake valve MAN Exhaust (Jack-Brake), among other qualities.

SERVICE AND REPAIR

We offer a state of the art repair and service facility for all our customers. For customers with road side emergency issues, we have two mobile service and repair teams’ available 24hours/7days/365days to meet our customer’s needs. We are establishing service and repair centers in all regions within Nigeria.

SPARE PARTS

Availability of spare parts "will never be a problem” as we always have a large stock of spares which will cover our entire customer needs. Beiben and Mercedes trucks share several interchangeable parts meaning that Beiben trucks can use original Mercedes Benz Actros and Atego (SK/NG) spare parts or alternatives to the Mercedes Benz SK / NG ranges. Cataloging and ordering of these parts are the same for both brands, making it easy to search and buy.

 china beiben 2538 dump truck



Product Description



Model

6x4 dump truck

Cabin

Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; With inner A/C

Engine

Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.

Model:

WP10. 380E32

WEICHAI Diesel engine



MAX Horse power:

380HP/280KW



Displacement(L):

9.726liter (Euro 2 standard)



Max torque:

1500NM@1200-1600rpm



Bore/stoke:

126mm/130mm

Gear box



Max torque:2000NM



Model:

12JS200T, mechanism,12gears,2reverse gear, manual, synchronization



Speed:

12speed,2reverse

Axle(front/rear)

Front axle

Double-shoe pneumatic brake, non-driving steering axle

Tandem

Double-shoe pneumatic brake, casting, double reduction driving axle

Clutch

Single dry frictional disc,Hydraulic boosting

Brake

Service brake: Brake gap can be adjusted automatically, double circulation air brake system



Parking brake: Potential springs pressing on middle and rear wheels



Engine brake: Engine exhaust brake(EVB)

Steering

TAS85, driver sit at the left hand side



Electric Equipment



Operating voltage:

24Vnegative grounded



Starter:

24V,5.4KW



Alternator

28V,758W



Battery voltage

12V/135Ah,cigar lighter

Frame

Fish belly, shape, variable width, variable sections, side beam structure.

Tyre

12+1 spare tyre with rim



12.00-R20

Suspension system: strongthen heavy duty Leaf spring type



Front/Rear

12/12/13

Dump body:

Inside size of Body(mm): 8900x2300x1000,6x8mm, made of high intensity steel

Lifting type: Front lifter “T” type hydraulic system.

Overall dimension(mm): 11730x2500x3484(Length x width x height)

Wheelbase

1950+4600+1450mm

Track:





Front/Rear

2045/1872



Approach/Departure angle

26/27



Front /Rear overhang

1410/2320



Max speed

90km/h

Kerb weight:

15500kg

Oil tank capacity

300L fuel tank



Low price for high quality China 30 ton truck 6X4 beiben dump truck



Low price for high quality China 30 ton truck 6X4 beiben dump truck

Low price for high quality China 30 ton truck 6X4 beiben dump truck

Low price for high quality China 30 ton truck 6X4 beiben dump truck
