Order(MOQ):
1Production time:
40 daysPayment terms:
T/T, West union
Function:
◆ High quality Concrete transportation
◆ Equipped with concrete pump truck, concrete bathing plant.
◆ Municipal road construction
◆ High way construction, replace benz mixer truck fleet.
Feature:
Key Features:
◆ World-class Beiben mixer truck Chassis, High power and Fuel efficiency, Reliability, Uptime
◆ The hydraulic system adopts Germany Rexroth, America EATON, Italy ARK, America Sauer for beiben concrete mixer truck
◆ Comfortable, spacious cabin with heating and air conditioning, high-grade stereo and sleep area.
◆ The mixing drum is made from the special close grain high-hardness steel plate B520JJ which is produced by Shanghai Baosteel and its service life can last 8-10 years;
◆ Equipped with the large diameter hopper, it can realize the quickly feeding, not plugging and spilling, and it is easy to clean;
◆ The optimized design of mixing drum ensure the concrete residue ratio is less than 1%;
◆ Mixer coverage 3cbm, 5cbm,6cbm, 8cbm, 10cbm, 12cbm, 14cbm, 16cbm.
Similar key words: beiben concrete mixer truck is also called as beiben transit mixer truck, north benz mixer truck. With full germany benz blood, beiben cement concrete mixer trucks are widely used for africa country, such as algeria, nigeria, congo, ghana, kenya, tanznaina. North benz transit mixer truck can be range from beiben 2528,2534,2538,3134,3138 concrete mixer trucks type.
More than 15 years experience on producing beiben concrete mixer trucks, beiben 8 CBM concrete mixer truck, beiben 9 CBM, 10 CBM transit mixer trucks. Supply original EATON, BONGLIFILI,ARK,TOP brand mixer truck upper stucture parts. As the most professional beiben concrete transportation trucks manufacturer in china, we will ensure the super quality and best price for all beiben truck customer.
The best north benz mixer truck supplier from china baotou beiben heavy duty trucks. The most professional beiben 6*4 concrete mixer truck work experience on beiben 2527,2628,2632,3630,2629,2634,2638 mixer trucks. Currently, we supply beiben LHD transit mixer truck with 2534 cabin, beiben RHD mixer truck with 2534 cabin.
| Beiben 2534 BY /6×4/3450+1450/Short Cab/LHD | ||||||
| Dimension | 9300*2500*3900mm | |||||
| Approaching angle/Departure angle | 26/20° | |||||
| Overhang(front/rear) | 1410/2640mm | |||||
| Wheel base | 3800+1450mm | |||||
| Max speed | 80km/h | |||||
| Curb weight | 13650kg | |||||
| Loading capacity | 11220kg | |||||
| Slope climbing capability | Max.40% | |||||
| Engine | Model | WP10.340E32，water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection | ||||
| Displacement | 9.726L/Diesel | |||||
| Stroke | 126/130mm | |||||
| Max. power | 250/2200 (kw/rpm) | |||||
| Max.torque | 1350/1200-1600（Nm/rpm） | |||||
| Emission stantard | EuroⅢ | |||||
| Fuel tanker capacity | 300L | |||||
| Clutch | ∮430, Single dry frictional disc，Hydraulic boosting | |||||
| Gearbox | 9T-160, mechanism,9 forward gears,1 reverse gear, manual operated, with synchronizer | |||||
| Gear ratio of gear box | 12.60/8.39/6.31/4.64/3.43/2.45/1.84/1.35/1.00 R: 11.02 | |||||
| Suspension system | Front | Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 10pcs | ||||
| Rear | Non-free standing stablization spring, balance suspension system, 13pcs | |||||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||||
| Assistant brake | Engine exhaust brake | |||||
| Park brake | Potential springs pressing on middle and rear wheels | |||||
| Steering system | TAS85,whole circulation in ball, hydraulic booster | |||||
| Frame | Fish belly shape, variable width, variable sections | |||||
| Front axle (Mercedes Technology) | Double-shoe pneumatic brake, non-driving steering axle | |||||
| Middle and Rear axle (Mercedes Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |||||
| Tyre | 12.00R20 Radial | |||||
| Electrical system | Battery | 2X12V/135Ah | ||||
| Generator | 28V-35A | |||||
| Starter | 5.4Kw/24V | |||||
| Cabin |
NG80B Long cabin with single sleeper; Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; High back with arm seat for driver, high back seat for co-driver; With inner A/C |
|||||
| Main technical parameters of Beiben concrete mixer | ||||||
| Drum performance parameter | Geometric Volume m3 | 15.5 m3 | ||||
| Effective Volume m3 | 10 m3 | |||||
| Filling Ratio % | 64.5% | |||||
| Gradient of the Drum ° | 15° | |||||
| Filling speed m3/min | ≥3 | |||||
| Discharging Speed m3/min | ≥2 | |||||
| Surplus Ration % | <1% | |||||
| Range of Slump mm | 20～300 | |||||
| Hydraulic System | Pump | Eaton 54 (ACA542337R) | ||||
| Motor | Eaton 54 (HHD542337R) | |||||
| Gear Box | PMB6sp | |||||
| Water supply system | Volume of water tank | 400L | ||||
| Water supply type | Air pressure Type | |||||
| Model | Engine Model | Rated Power | Payload | Driving Mode |
| Beiben 2534 |
WP10.340 |
340 Hp |
10 CBM |
6*4 |
| Beiben 3134 | WP10.340 | 340 hP | 14 CBM | 8*4 |
| Beiben 2534 | WP10.340N | 340 Hp | 10 CBM | 6*4 |
| Beiben 3138 | WP10.380 | 380 Hp | 14 CBM | 8*4 |
| Beiben 2538 | WP10.380E | 380 Hp | 10 CBM | 6*4 |
| Beiben 2529 | WP10.290E32 | 290 Hp | 8 CBM | 6*4 |
Watch Beiben 2534 mixer on YOUTUBE.
Beiben 2534 concrete mixer trucks are into inspection before exporting.
How to operate beiben transit mixer truck ?
Beiben 2534 mixer truck is shipping on RORO vessel :
http://www.beiben-trucks.com/8-units-beiben-2534K-concrete-mixer-truck-in-stock-for-exporting-_n117
as the best beiben V3 transit mixer trucks manufacturer in china, we aim at supplying the best quality beiben V3 mixer trucks and beiben V3 8 CBM mixer truck, 10 CBM mixer truck and beiben 14 concrete mixer truck.
beiben 2534 v3 concrete mixer trucks in cheap price and best quality, 100% china beiben V3 6*4 concrete mixer truck supplier.
Beiben NG80B 8 CBM cement mixer trucks, the china best beiben 6*4 concrete mixer truck manufacturer in china.
Beiben 8*4 drive system, germany benz technology 7 T double front axle, benz 17 T double rear axle, fast 12 shift gear box , 12.00R20 tyre. 14 CBM drum capacity with CEEC TRUCKS lastest technology on mixer trucks.
Beiben 2534 transit mixer truck chassis, 340 Hp engine europen technology, fast 9 shift transmission, benz 7 T front axle , benz technology 16 double rear axle, 12.00R20 tyre. 3800+1450 mm wheelbase.
beiben V3 10 CBM concrete mixer trucks, with weichai 340 Hp engine, fast 9 shift transmission, benz technology 7 T front axle, benz technology 13 T rear double axle, V3 cabin with air condition. 10 CBM drum.
Beiben 2534 concrete mixer truck chassis, 6*4 driving system, beiben unique weichai 340 hp engine, fast 9 shift transmission, with benz 7 T front axle, 16 T benz rear axle, with 9 CBM mixer truck drum, America Eaton oil motor and pump, Itlay reducer, china famous radiator
Beiben 9 CBM concrete drum capacity, weichai 340 Hp engine, America Eaton oil pump and motor, fast 9 shift transmission, benz quality assurance.
beiben 2528 cement mixer truck manufacturer , benz quality 2528 cement mixer truck chassis, 280 hp engine, with super quality concrete mixer drum, 3450+1350 mm wheelbase.
