Order(MOQ):
1Beiben 2534 fuel tanker truck 6 wheel drive for congo country.
The most professinal beiben 2529,2534,2538,2542 fuel tanker truck, water tanker truck, truck mounted crane, fire truck manufacturer in china.
| 16m3 BeiBen 6*6 fuel tanker truck |
|
|||
| Item |
Descriptions |
Spesifications and Types |
|
|
| Vehicle |
Brand |
CEEC |
|
|
| Model |
CEEC5256GJYZ |
|
||
| Overall Dimensions L*W*H |
10465x2500x3420mm |
|
||
| Weights |
GVW. |
25,000kgs |
|
|
| Curb Weight |
12,270kgs |
|
||
| Rated Payload |
12,600kgs |
|
||
| Chassis |
Brand |
BeiBen |
|
|
| Model |
ND1250F50J |
|
||
| Drive Type |
6x6 |
|
||
| Steering |
RHD or LHD, power assisted steering |
|
||
| Engine |
Brand |
WeiChai |
|
|
| Model |
WP10.375 |
|
||
| Power |
276Kw /375HP |
|
||
| Displacement |
9726ml |
|
||
| Emmission Level |
EURO 3 |
|
||
| Max. Torque |
970Nm at 1400rpm |
|
||
| System |
Inline six-cylinder electronic control system Enhanced high pressure common rail particle filter |
|
||
| Performance |
Max. Speed |
80km/h |
|
|
| Wheel base |
5050+1450mm |
|
||
| Tyre Specifications |
12.00-20 |
|
||
| No. of Tyre |
13pcs (1 spare tyre included) |
|
||
| Axle Capacity |
Front 8 Tons & rear 12Tons |
|
||
| Transmission |
8 forward gears & 1 reverse, Manual |
|
||
| Brake |
Oil brake,drum brake |
|
||
| Suspension |
Leaf spring |
|
||
| Electics |
24V |
|
||
| Cab |
Cab Capacity |
3 persons allowed |
|
|
| Cab Type |
One and a half row |
|
||
| Body/Superstructure |
Tank |
Capacity |
16 m³ |
|
| Material |
tank shell 5mm ,dished ends 6mm,compartment boards 5mm,the material is carbon steel |
|
||
| Loading System |
Top filling from manhole or pump fuel into tank from oil inlet valve. |
|
||
| Discharging System |
Pump fuel out from tank or gravity discharge. |
|
||
| Basic |
Install fuel pump drive by truck engine through PTO; One manhole, two pcs of fuel hoses (3inches) with complete quick connectors, access ladder, tank top anti-slip steel mesh installed, anti-static device, one fire extinguisher, with two corners’ lights and reflective tape. |
|||
| Paint |
Rust proofing primer + undercoat +2 finish coats = 4; |
|
||
| Optional Equipments |
Air Conditioner |
|
||
| Tyre type:12.00R20 |
|
|||
| Tank material:Stainless steel |
|
|||
| The tank thickness :5mm carbon steel |
|
|||
| Bottom loading |
|
|||
| Flow meter, rolling hose with nozzle, emergency valve, compartment number, epoxy coating inside tank |
|
|||
Beiben oil carrier 25000L fuel tank truck oil off road tank truck price, Condition: New Storage: Oil Drive Wheel: 6x4 Horsepower: 251 - 350hp Transmission Type: Manual Fuel Type: Diesel Tank Volume: 15001 - 30000L Engine Capacity: 9.726L Dimensions (L x W x H) (mm): 8.4x2.5x3.2 Brand Name: Beiben Place of Origin: Shandong, China (Mainland) Model Number: 2534
BEIBEN tank truck/20cbm tanker/oil tank truck camion, the best beiben 20 T fuel tanker truck manufacturer, supply the best quality beiben tanker truck.
Beiben 2534 wheel drive fuel tanker truck, produced base on china north benz 6*6 wheel drive 340 Hp engine truck chassis, with beiben military truck technology, fast 9 shift transmission.
Beiben 2534 airport off road fuel tanker truck, widely used for refueling the airplane at the airport, based on beiben 340 Hp engine truck chassis, with Germnay technology upper structure system. very convenient and reliable for charge the air gas . 10 CBM fuel tanker capaicty .
Beiben 2534 off road tractor truck, based on beiben 2534 off road tractor truck chassis, 6*6 driving system, with germany benz technology cabin and axle, this kind of north benz 6 wheel drive tractor can be used in extremely tough road situation.
Beiben 2530 truck chassis, WEICHAI Euro 2 engine 300 hp , fast 9 shift transmission, 4500+1350 mm wheelbase, 7 T benz front axle, 13 T double rear axle with wheel reducer, 11.00R20. CEEC latest technology on 20 cbm fuel tanker trucks.
China best beiben fuel truck manufacturer, Beiben 2530 oil truck chassis, with 300 hp engine , fast 9 shift transmission, 4500+1350 mm wheelbase, 7 T benz front axle, 13 T double rear axle with wheel reducer, 11.00R20.
This beiben 20 cbm fuel tanker truck is for congo customer, WP10.340 diesel engine, fast 9 shift transmission, wheelbase 4450+1450 mm, 12.00R20 tyre. the beiben 2634 truck chassis is with mercedes benz NG80B cabin, mercedes benz front axle and rear axle .This heavy duty beiben 2634 cargo truck chassis can be produced beiben oil tanker truck, beiben water tanker truck and other beiben cargo trucks.
Beiben 2534 tractor truck for congo customer, china best beiben 2534 tractor truck supplier for beiben 6*4 drive system beiben 340 Hp engine tractor truck, builted on benz truck chassis, with congo customer's beiben 2534 tractor truck spare parts service.
