Beiben 1929 RHD AWD water truck, specially built for Tanzania, is equipped with WEICHAI WP10.290E32 diesel engine, providing 290 horsepower. Equipped with FAST 9JS150A gearbox, it supports 9 forward gears and 1 reverse gear, adapting to various operation requirements. It has a 12,000-liter large-capacity water tank and an efficient water pump, providing excellent watering performance.
Production time:
30 daysPayment terms:
TTWorking Capcity:
12000 litersEngine power:
290 HPDrive system:
4×4Porudct Description
Beiben 1929 RHD water tank truck is a customized vehicle for Tanzanian customers. This Beiben off-road water bowser is based on the NG80 series and adopts a 4X4 all-wheel drive design to ensure stable driving under various road conditions. The full load mass of the vehicle reaches 19,000kg, while the dead weight is only 7,500kg. This high load capacity makes it easy to perform watering tasks. In addition, the vehicle adopts a right-hand drive design, which conforms to the local driving habits in Tanzania.
In terms of the power system, the Beiben 4×4 water truck is equipped with a WEICHAI brand WP10.290E32 diesel engine with a displacement of 9.726L. It adopts inline six-cylinder, four-stroke, water-cooled, direct injection, and intercooled turbocharging technology to ensure strong power output and efficient fuel economy.
The Beiben 1929 RHD water tanker truck is equipped with BEIBEN 430 diaphragm spring clutch and FAST 9JS150A 9-speed gearbox, providing 9 forward gears and 1 reverse gear to meet different driving and operation requirements. The vehicle's inter-axle differential lock and rear axle differential lock design ensure passability and stability under complex road conditions. In terms of the braking system, a dual-circuit compressed air braking system and engine exhaust brake are used as auxiliary brakes. It is also equipped with a spring energy storage front brake and a compressed air rear brake as a parking brake to ensure driving safety.
The upper body of the water truck is its core function. This Beiben 4×4 water spray truck is equipped with a carbon steel water tank with a capacity of 12,000 liters, ensuring sufficient watering capacity. And the vehicle is also equipped with a water pump model 80QZF-60/90N, with a maximum flow of 60m³/h and a head of up to 90m, providing strong support for the cleaning and greening of urban roads.
Product Specifications
|
General Specification |
||
|
Chassis Model |
Beiben 1929 |
|
|
Series |
NG80 |
|
|
Wheel Traction / Drive Style |
4X4 |
|
|
Full Load Mass Weight |
19000kg |
|
|
Curb Mass/ Self Weight |
7500kg |
|
|
Steering Wheel Position |
RHD (Right Hand Drive) |
|
|
Engine |
||
|
Model |
WP10.290E32 |
|
|
Brand |
WEICHAI |
|
|
Displacement |
9.726L |
|
|
Type |
In-line, Six-cylinder, Four-stroke, Water-cooled, Direct Injection, Intercooled Turbocharged Diesel Engine |
|
|
Engine Classification / Standard |
EURO III EGR |
|
|
Bore/Stroke |
mm |
126/130 |
|
Rated Horse Power |
hp |
290 |
|
Net Power |
KW/rpm |
213KW/2200rpm |
|
Torque (Nm/rpm): |
Nm/rpm |
1160Nm @ 1200-1600rpm |
|
Clutch & Gear Box Systems |
||
|
Clutch |
BEIBEN's 430 diaphragm spring clutch |
|
|
Gear Box |
FAST 9JS150A |
|
|
Gear Speed/Lever |
9 forward/ 1 reverse |
|
|
Gear Ratio |
12.57,8.39,6.15,4.59,3.4,2.47,1.81,1.35 |
|
|
Axle & Steering |
||
|
Steering Model |
8098 |
|
|
Front Axle |
7T |
|
|
Rear Axle |
13T , Drum Brake |
|
|
Ratio of Rear Axle |
5.263 |
|
|
Loading Capacity per Axle |
front |
7000kg |
|
rear |
13000kg |
|
|
Brake System & Suspension |
||
|
Service Brake |
dual circuit compressed air brake |
|
|
Auxiliary Brake |
engine exhaust valve brake |
|
|
Parking Brake (Emergency Brake) |
front |
spring energy |
|
rear |
compressed air |
|
|
Suspension Type |
front |
10pcs leaf spring |
|
rear |
13pcs leaf spring |
|
|
Wheels & Tires |
||
|
Wheel Type |
Radial Tires |
|
|
Number of Tires |
6+1 (spare tire) |
|
|
Tire Type/Size |
12.00R20 |
|
|
Track |
front |
1995mm |
|
rear |
1800mm |
|
|
Upper-body Specifications |
||
|
Water tanker |
capacity |
12000 liters |
|
material |
Carbon steel |
|
|
Water pump |
model |
80QZF-60/90N |
|
flow rate(L/m) |
60m3/h |
|
|
head of delivery |
90m |
|
|
Input speed |
1180 r/min |
|
Product Details Display
Beiben 4*4 drive trucks are used for military department, our beiben 4 wheel drive trucks enjoy great reputation in foreign market.
Best beiben 4 wheel drive truck supplier in china, Beiben 4*4 drive trucks are used for military department, our beiben 4 wheel drive trucks enjoy great reputation in foreign market.
Beiben 4*4 drive cargo truck with crane , china weichai diesel 300HP engine, fast 9 shift transmissin. benz truck technology,
Best Beiben ND12502B41J all wheel drive truck 300 hp for kenya country, tanzania country, Nigeria country, Congo country. We are the best supplier for beiben 4*4 truck chassis.
Beiben ND1290 military truck for exporting , tanzania country, Nigeria country, Congo country. We are the best supplier for beiben 4*4 truck chassis.
China 4 wheel drive military truck supplier for beiben truck, military axle from germany benz technology, beiben 1929A , weichai 290 hp engine, 11.00-20 tyre.
North benz V3 cabin 4 drive military truck supplier for beiben truck, Germany technology military axle from germany benz technology, beiben 1929A , weichai 290 hp engine, 11.00-20 tyre.
UN 4*4 wheel drive military truck, special benz technology quality ensurance for UN force using, very reliable for UN military from china baotou beiben heavy duty truck co.,limited
Beiben 4x4 truck chassis is world widely know as Beiben 1822 cargo truck, Beiben 1929 cargo truck. Drive mode 4x4 means four-wheel full drive, which is suitable for use environments that require strong off-road performance and stability. The Beiben 4x4 offroad type of chassis is usually equipped with a high-performance engine WEICHAI diesel type and transmission system FAST brand, as well as good load-bearing capacity with Mercedes Benz technology 7.5tons front axle and 13tons rear axle, and durability to meet the transportation needs of long-distance, heavy-loaded and harsh road conditions. Beiben cargo trucks can customize the chassis according to customer needs, including wheelbase, number of tires, engine model, etc., to meet the specific needs of different customers. Specially Beiben NG80B cabin can be customized as any color as required.
