Beiben 4×2 chassis specifications

The Beiben 2642 6×6 cargo chassis is equipped with a WP12.420E32 engine, boasting a maximum power of 309 kW (420 horsepower) and a maximum torque of 1750 Nm, while complying with EURO 3 emission standards. Featuring a fish-belly variable-width and variable-section frame design, with both front and rear axles utilizing Mercedes-Benz technology and a gear ratio of 5.263, it ensures stable driving under complex road conditions. The dual-circuit air brake system is equipped to guarantee driving safety. The interior design is humanized, with a full steel frame and double-layer steel plate for sound insulation, providing a spacious and comfortable driving environment.

The Beiben 2642 NG80 6×6 chassis, integrating German Mercedes-Benz technology, features a fish-belly frame design and is equipped with a WP12.420E32 engine (309Kw/420HP), a 12JS200T transmission (12-speed), and a 6×6 all-wheel drive system. Its non-independent suspension and Mercedes-Benz axle technology ensure excellent off-road capability and load stability. With intelligent control, comfortable interiors, and a robust electrical system, it provides users with a durable, reliable, and comfortable heavy-duty transport solution, suitable for a variety of complex operating conditions.

The Beiben 8×8 all-wheel-drive chassis features a tri-axle twelve-wheel design with a wheelbase of 1500+5050+1450mm. The overall dimensions are 12100X2700X3400mm, and the curb weight is 10800kg. It is equipped with a WP12.420E32 diesel engine, rated at 319Kw (420HP), mated to a 12JS200T transmission. The chassis is fitted with a dual-circuit air brake system and a full-circulating ball-type steering system, and utilizes a fish-belly high-strength frame. With its ability to adapt to various complex environments, it is a preferred choice in the field of off-road transportation, widely used in petroleum exploration, mining, military operations, and rescue missions.

Beiben 2642 cargo chassis is a truck chassis designed for heavy-duty transportation, with dimensions of 10500×2500×3840mm, a total mass of up to 25000kg, and a strong carrying capacity. It is equipped with a WP12.420E32 engine with a maximum power of 309kw/2100rpm and a maximum torque of 1600Nm/1800rpm, which is powerful. It is equipped with a 12JS200T gearbox with 12 forward gears and 2 reverse gears, and shifting is smooth. In addition, it also has excellent braking and steering systems, as well as a comfortable driving environment, making it a leader in the freight field.

Beiben 4×2 chassis is a high-performance chassis designed for heavy-duty transportation, with excellent driving ability. Its wheelbase is 4500mm, the overall dimensions are 7990×2495×2965mm, and the gross vehicle weight reaches 18000kg. The chassis is equipped with a WP10.240 engine with a rated power of 175Kw (240HP) and an emission standard of EURO 3. The transmission system adopts a 9JS150A mechanical gearbox, equipped with a dual-circuit air brake system and hydraulic power steering. Its fuel tank capacity is 400L, which is suitable for long-distance driving needs.
